ODOT-S7MPI V2.0 PPI MPI PROFIBUS Interface to EtherNet Protocol Converter
Product Details
ODOT-S7MPI V2.0 is used for Siemens SMART 200/S7-200/S7-300/S7-400/Siemens CNC840D,840DSL, HEXIN, EWE PLC's PPI/MPI/ PROFIBUS interface conversion into Ethernet fordata acquisition, which is very convenient forthe construction of production management system. ODOT-S7MPI V2.0 does not occupy the PLC programming port, that is, the programming software/hostcomputersoftware monitorsand gathers PLCdata through Ethernet, whilethe touch screen can communicate with PLC through the extension port, it is plug and play.
Technical Parameters
Mechanical
Installation: Plug and Play
Weight: 60g
Dimension: 65*30*17mm
Operating Temperature: 0 〜60℃
Humidity: 5 〜95%(No Condensation)
Input Voltage: 24 VDC±20%
(Usually no need external power supply)
Power Supply Mode: Direct Power Supply from PLC Communication Port
Power: Max.l00mA@24V
Ethernet Interface
Protocol: S7 Ethernet, Modbus-TCP
TCP Connections: Max. 32
Ethernet Port Quantity: 1
Rate: 10/100Mbps, Self-Adaption MDI/MDIX
Interface: 8PinRj45
X2 Interface
Interface Type: DB9⑴
Baud Rate: 9.6K~1.5Mbps
Connectable Device: Connect to Siemens' Communication Equipmentsuch asTouch Screen, CP5611 Communication Card, etc
S7 Interface
Supported Protocol: PPI/MPI/PROFIBUS
Interface Type: Db9(l)
Baud Rate: 9.6k-l.5Mbps, Self-Adaption
Others
Certificate: EMS,CE
Warranty: l year
Provide Web Configuration: Default 192.168.1.188
Provide Interface Driver Files: NetS7PD
Provide Testing Software: NetDevice
