CT-121F: 16 channel digital input/24VDC/ Sink type
CT-121F：16 channel digital input/24VDC/ Sink type/The input high level is valid
Module features
◆ the module supports 16 channels digital input, supports sink input, and input voltage is 24VDC.
◆ the module can collect digital output signal of field equipment (dry contact or active output).
◆ the module can be accessed to 2-wire or 3-wire digital sensor.
◆ the internal bus and field input of the module use opto-isolator.
◆ the module supports the input signal holding function, and the holding time can be set.
◆the module carries 16 digigtal input channels with LED indicator on each channel.
◆ supports counting function, by adding counting sub-module.
◆ each input channel of the module supports a 32-bit counter with the counting frequency <200Hz.
◆ the module can set the digital signal input filtering time and the byte transmission order of the counter.
◆ each channel of the module can set the counting mode and counting direction independently.
-
CT-3134 4 channels Voltage Input
CT-3134 4 channels Voltage Input 0~5/0~10/±5/±10VDC,15 bits /16 bits
Module features
◆ The module supports 4 channels of voltage signal input
◆ The module can capture 0~5VDC, 0~10VDC, ±5VDC, ±10VDC,with 15 bits, 16 bits resolution
◆ The module carries with 4 analog input channel LED indicator
◆ The module input signal is a single ended common grounding input
◆ Filtering time can be set
◆ Channels can be disabled independently
◆ With isolation between channels
-
ODOT-MS100T/100G Series : 5/8/16 Port Unmanaged EtherNet Switch
MS100T
10/100 Mbps self-adaption,(Auto-MDI/MDI-X)
Supports IEEE 802.3 for 10BaseT
Supports IEEE 802.3u for 100BaseT and 100BaseFX
Supports IEEE 802.3xfor flow control
Supports broadcast storm protection
Supports working temperature: -20~70℃
5/8/16 ports unmanaged Ethernet Switches DIN-rail
-
CT-7339 18 channels field power distribution module（24VDC/0VDC）
Module features
◆ Support on-site power distribution, output is 24VDC/0VDC
◆ Support expansion of 18 channels ,9 channels of 24VDC ,9 channels of 0VDC.
◆ Requires no configuration and occupies no slot in configuration. -
CT-7346 18 channels field power distribution module（24VDC/0VDC/PE）
Module features
◆ Support on-site power distribution, output is 24VDC/0VDC.
◆ Support expansion of 18 channels ,6 channels of 24VDC ,6 channels of 0VDC ,6 channels of PE.
◆ Requires no configuration and occupies no slot in configuration. -
CT-7220: Power Supply Extension Module 5V/2A
CT-7220 Power Supply Extension Module 5V/2A
◆ System Power and Field Power Extension
◆ System Power Output 2A@5VDC
◆ Field Power Extension 8A Current
◆Take no module channel(replace CT-7221) -
CT-623F: 8 digital input&8 digital output /24VDC/ source or sink
CT-623F: 8-channel digital input /24VDC/ source or sink type & 8-channel digital output /24VDC/ source type
Module features
◆ The module supports 8-channel digital input, and supports source type and sink type two-way input. The input voltage is 0V/24VDC.
◆ The module supports 8-channel digital output, Output high level valid, and the output voltage is 24VDC.
◆ Module input channel can collect digital output signal of field equipment. (dry contact or active output)
◆ The module input channel can be connected to the 2-wire or 3-wire digital sensor.
-
CT-5321: Modbus Serial Port Module
CT-5321 Modbus Serial Port Module
1 Module Description
The Modbus serial port module supports 1 channel RS485/RS232 /RS422(optional), supports Modbus RTU/ASCII protocol, and supports master, slave and free transparent transmission mode.
The serial Module CT-5321 could be applied with the adapter modules, so it could convert Modbus into other protocols such as Modbus TCP, Profinet, EtherCAT, EtherNet/IP, etc. When the module is used, serial port parameters and Modbus instructions should be configured in IO Config software.
Devices with RS485/RS232/RS422 interface, which support modbus-RTU/ASCII, could be applied with CT-5321 to realize interconnection with upper PLC or upper computers. CT-5321 could be applied with devices such as: PLC, DCS, remote IO, VFD, motor start protection device, intelligent high and low voltage electrical apparatus, power measurement device, intelligent field measurement equipment and instruments, etc.
-
CT-5721: Bus extended slave module
CT-5721 Bus extended slave module
The bus extened slave module is used to extend the bus.The bus extended slave module has no process data and configuration parameters.
-
CT-5801: Terminal module
CT-5801: Terminal module
Terminal modules are used to stabilize the internal bus communication.Each C series I/O protocol adapter must be equipped with 1pc of terminal module CT-5801 no matter how many sub-modules are connected.
The dustproof terminal could cover the internal bus and field power supply hardware of the last IO module.
And terminal modules have no process data and configuration parameters.
* Take no module channel and replace CT-5800.
-
CT-5112 2-channel encoder input/24VDC
Module features
◆ the module supports two channels of encoder input.
◆ each encoder channel supports A/B incremental encoder or pulse-directional encoder input.
◆ each encoder channel supports orthogonal A/B signal input, input voltage 24V, and it supports source and sink input.
◆ the incremental encoder mode supports x1/ x2 / x4 frequency multiplication mode.
◆ the pulse – direction mode supports nondirectional signal, pulse input only.
◆ each encoder channel supports 1 digital input signal with an input voltage of 5Vdc or 24Vdc.
◆ each encoder channel supports 1 digital output signal with an output voltage of 24Vdc.
◆ each encoder channel supports 1 way of 24V power output, which can be connected to the encoder for power supply.
◆ the module internal bus and field input adopt magnetic isolation.
◆ the module carries 16 LED indicators.
◆ the maximum input frequency of the encoder supported by the module is 1.5MHz.
◆ the module supports measurement function, it could detect the load speed or input signal frequency.
-
CT-5711: Bus extended master module
CT-5711 Bus extended master module
Module Description
The bus extened master module is used to extend the bus.The bus extended master module has no process data and configuration parameters.
